Hyperchill
Chillers designed to provide precise and accurate temperature control for a wide variety of industrial applications, with cooling capacities from 76 kW to 360 kW @ 25°C ambient temperature.
Unichill Limited takes individual items of equipment needed for your process and packages them into a CE marked single piece of plant.
This allows the Unichill team to carry out all the detailed integration works at our factory and enables us full test all the items prior to arriving on site. This also massively reduces the installation and integration time on site reducing risk and disruption.
Included in our packages is a complete drawing pack including 3d models, detailed component lists, signal interface lists, testing documentation to full test the.
Our packaged equipment comes with performance and availability guarantees showing the confidence we have with every item of plant that leaves our factory.
Installation
Extremely compact and easy to use, Hyperchill
ensures an accurate control of water temperature.
Each model is designed for safe and reliable opera-
tion in the most varied working conditions, thanks to
the modern technical solutions used and the availa-
bility of a wide range of accessories and options.
Each individual Hyperchill unit is extensively tested to
guarantee efficient operation and reliability in all
working conditions.
Applications
- Laser Technology
- Extruders
- Surface Processing
- Welding Engineering
- Blow Mould Machines
- Printing Systems
- Coating Systems
- Chemical and Pharmaceutical
- Plastics Processing
- Thermoform Machines
- Plasma Coating
- Medical Imaging
- Food & Beverage Industry
- Injection Moulding
- Cutting Machine Tools
- Electroplating Baths
- Bioenergy
- Compressed Air
High reliability and back-up eliminate downtime
Water and refrigerant manometers:
Permit full control of the working conditions.
Microprocessors
permit full control of the unit parameters. Proprietary software allows a wide range of programming and remote monitoring options.
Compliant scroll compressors:
with less moving parts and compliant technology provide excellent efficiency, high reliability, and very low noise levels.
| Model ICE | 076 | 090 | 116 | 150 | 183 | 230 | 310 | 360 | |
|---|---|---|---|---|---|---|---|---|---|
| Cooling capacity | KW | 76,0 | 90,2 | 115,5 | 149,2 | 182,3 | 228 | 309 | 360 |
| Compressor abs | KW | 15,4 | 20,3 | 24,9 | 30,8 | 40,1 | 51,4 | 65 | 82 |
| SEPR3 | 5,39 | 4,97 | 5,08 | 5,35 | 5,04 | 4,80 | 5,51 | 4,57 | |
| Power supply | V/ph/Hz | 400/3/50 no neutral | |||||||
| Protection index | 54 | ||||||||
| Refrigerant | R407C | ||||||||
Complete solution, easy to install and manage
Hydraulic circuit: water tank, immersed evaporator, pump with bypass provide a compact and easy to install solution.
Electronic controllers with proprietary software provide access to all the parameters of the units and allow special management for any specific need. • Available with remote monitoring.
Completely configurable with many options and kits to fit many industrial applications needs. • Condenser filters.
Independent condensing plenum.
Full access and easy service design. High reliability and back-up eliminate downtime
Large water tanks allow minimum compressor cycling and precise temperature control.
Double independent fridge circuits.
2 compressors from ICE076 and 4 compressors from ICE150 with automatic rotation.
Double stand-by water pumps available.
Maximum ambient temperature up to 45 °C. Lowest energy consumption in the market
Oversized condensers and evaporators.
Use of compliant scroll compressors.
Technical data
Product features
Complete solution, easy to install and manage
Hydraulic circuit: water tank, immersed evaporator, pump with bypass provide a compact and easy to install solution.
Electronic controllers with proprietary software provide access to all the parameters of the units and allow special management for any specific need. • Available with remote monitoring.
Completely configurable with many options and kits to fit many industrial applications needs. • Condenser filters.
Independent condensing plenum.
Full access and easy service design. High reliability and back-up eliminate downtime
Large water tanks allow minimum compressor cycling and precise temperature control.
Double independent fridge circuits.
2 compressors from ICE076 and 4 compressors from ICE150 with automatic rotation.
Double stand-by water pumps available.
Maximum ambient temperature up to 45 °C. Lowest energy consumption in the market
Oversized condensers and evaporators.
Use of compliant scroll compressors.
– Options
Water fill kits
Pressurised, automatic or ambient manual kits, for water filling in any installation.
Remote control kits
Remote control kits: base version for remote ON/OFF and general alarm monitoring. Advanced version for complete remote unit management.
Water filters
Water filters for circuit cleanliness and machinery protection.
